117 decibel signal-to-noise ratio delivers peerless performance.

117 decibel signal-to-noise ratio delivers peerless performance.

MBL 1611 F

Digital to Analog Converter

MBL 1611 F

Digital to Analog Converter

Digital to Analog Converter MBL 1611 F

In today’s digital world, consumers have endless options when it comes to enjoying music. They can use streaming services from Spotify, Amazon, Tidal, Qobuz, Deezer or Apple, to name but a few. They can also listen to their favorite playlists from mobile phones, tablets, USB sticks and, of course, conventional portable media in CD/PCM formats. Yet no matter the format, all devices share the same need – to convert digital music data into the analog world, something a tiny microchip can adequately manage.

Or you can move beyond adequate to brilliant with a 23-kilogram (50 lbs.) D/A converter firmly planted on solid brass pillars milled right in our own factory; a stand-alone device whose creators have left nothing to chance: the MBL 1611 F. Under the massive, gold-plated cover plate, two top-end converter designs – 1-Bit/Delta-Sigma and Multibit – take care of the accurate assignment of analog voltage values to the digital music signals. The combined technological strengths of each converter create a fantastic sense of aural space and the meticulous reproduction of the finest overtones, without compromising tight control of the deepest octaves. Together they deliver the delicate fragility of the most emotional musical passages, or thundering chest-pump bass notes when the data demands it. Using “single-stage” output electronics, the music signal leaves the digital/analog converter in the most direct way, either via balanced (XLR) or single-ended (RCA) outputs, ensuring as little interference as possible with few contact surfaces and short signal paths. The reward for this circuit layout: an incredible 117 dB signal-to-noise ratio.

The 1611 F displays similar flexibility on the incoming side. An impressive array of XLR, RCA, Toslink (optical) and USB inputs await digital signals with up to 24-bit resolution and a 96 kHz sampling rate. In order to reduce unwanted jitter often associated with inferior USB players such as computers, mobile phones or tablets, a superb master clock takes charge of the timing and provides stable square-wave signals for precise processing of the bitstream to come. Ideally, when playing CDs, the converter receives its signals already perfectly prepared into bite-sized chunks by its dream partner, the MBL 1621 A CD transport, and astonishes the listener with a playback quality that is unrivalled.






€ 28 300

piano black/gold

piano black/chrome

piano white/gold

piano white/chrome

* custom colors available

Optional network input with Roon

Say goodbye to the days when high-end sound and ease-of-use were incompatible. With Roon, your stored music files merge with those from your streaming service and your MBL high-end music system. Everything is one, with ease of operation from your smartphone or tablet.

When it comes to different music formats that your hardware may not readily distinguish, Roon does the work for you by instantly recognizing the possibilities of the hardware and smoothly adapting the signal to the highest possible quality and consistency.

All the benefits of Roon are now available as an option on the N31 CD-DAC, ready to be combined with the brilliant sound of your MBL music system.

True Peak Technologie

The simple calculation, 16 x 6 = 96, represents the dynamic range of a CD, meaning the ratio between the quietest sound a disc can store and the loudest noise it is capable of producing as defined in decibels. The audio tracks of the CD are encoded with 16 bits. Each bit delivers a dynamic range of 6 decibels, making a total of 96 decibels of dynamic range.

One might think that would be enough to flawlessly capture a piece of music on a digital file or CD recording with the lowest levels of the music sufficiently far away from noise, and with enough safety distance from distortion-prone overloads. This is the assumption of the major manufacturers of digital-analogue converter chips, such as AKM, ESS or Texas Instruments (Burr-Brown).

Unfortunately, audio reality paints a completely different picture, especially with pop music where overdriven recordings are the order of the day. Every music producer wants his songs to be loud and dynamic when they reach the audience’s ears. What could be achieved by any listener with a simple turn of the volume knob is built in right from the start by many recording studios where producers encode the music signal hard and fast to the maximum level. This is to the detriment of the highest-quality music playback. If several samples on a CD are fully distorted one after the other, the digital filters of the converters generate waveforms that are overdriven by up to three decibels – and are then abruptly cut or “clipped.” Unpleasant distortions are the audible and measurable outcome of this practice.



Fortunately, this is not the case with MBL's converter design. With sophisticated stop-gaps built into the digital filters, MBL’s engineers have ingeniously created an additional modulation reserve of three decibels, thereby correcting and basically eliminating any sound-degrading overloads from CD or music files. We call it True Peak Technology. Listeners call it extraordinary. The result is natural, distortion-free sound from CDs and digital music files – even at peak volume levels.

Extraordinary, indeed!

The MBL 1611 F at a glance

  • Chassis milled from a single block of aluminum
  • Natural reproduction through group-delay-optimized digital and analog filters
  • USB input (Audio Class 1) with Master Clock Mode for asynchronous, jitter-free data transfer
  • Commanding signal-to-noise ratio of 117 decibels
  • Combination of Delta-Sigma and Multi-Bit conversion
  • MBL True Peak Technology to eliminate mastering inaccuracies
  • Perfecter partner for the MBL 1621 A CD Drive
  • The possibility of connecting a PC/Mac/iPhone/iPad via USB; no driver installation required
  • Separate power supplies for analog, digital, and display functions
  • “Roon Ready” network input card (optional) for seamless connection to the Roon platform

Technical Specifications

D/A Converter Technology Multi level Delta Sigma
Sample Rates 96, 48, 44.1, 32 kHz
Resolution 24 bit linear
Signal-to-noise ratio 117 dB
Digital inputs 1 x XLR (AES/EBU) + 1 x optional 1 x RCA (S/P DIF) + 1 x optional 1 x BNC (S/P DIF) optional 1 x Glas ST optional 1 x Toslink + 1 x optional 1 x USB Link
Digital outputs 1 x RCA (S/P DIF)
Analog outputs 2 x RCA 1 x XLR
Weight 23 kg / 50.5 Ibs
